Specification
| Projection Features | ||
| Display Type | DLP Single 0.65" WXGA |
|
| Resolution | Resolution: 1280 x 800 pixels, 16:10 Resolution Support: VGA(640 x 480) to WUXGA_RB(1920 x 1200) |
|
| Brightness | 3,500 Lumens |
|
| Projection Distance | 80"~100" (with wall mount) | |
| Contrast Ratio | 10,000:1 | |
| Video Formats | NTSC, PAL, SECAM |
|
| Lamp Details | ||
| Type | Lamp (240W) |
|
| Lamp Life | Normal 5000 hrs; Economic 8000 hrs; SmartEco 10000 hrs; LampSave 12000 hrs |
|
| Audio | ||
| Built-in Speaker | 10W x2 |
|
| Connectivity | ||
| Interface | HDMI-1 X 1 HDMI-2 X 1 PC (D-sub 15pin) X 1 Monitor out (D-sub 15pin,Female) X 1 Composite Video in (RCA) X 1 Audio in(mini jack) X 1 Audio L/R in (RCA) X 1 Audio out (mini jack) X 1 LAN Port(RJ45 for Network ) X 1 RS232 In (D-sub 9pin, male) X 1 USB TypeA (5V,1.5A) X 1 USB Type B (For service) X 1 USB Type mini B (For PointWrite module) X 1 IR Receiver(Front) X 1 |
|
| Power | Power Consumption (Max/Normal/Eco): Max 350W. Normal 320 W. Eco 260 W. Standby Power Consumption: Normal < 0.5Watts. Network < 2W. Power Supply: 100 ~ 240V AC |
|
| External Features | ||
| Color | White | |
| Weight | 5 Kg+/- 100g |
|
| Dimension | 287.5x 206.9 x 373.3 mm |
|
| Warranty | ||
| Manufacturing Warranty | 2 years Parts & Service warranty |
|
| Parts Warranty | Lamp: 1000hrs warranty | |
